Modern Control Systems

Dorf

Chapter 2 Mathematical Models of Systems - all with Video Answers

Educators

Chapter Questions

Problem 1

An electric circuit is shown in Figure P2.1. Obtain a set of simultaneous integrodifferential equations representing the network.
Figure can't copy

Check back soon!

05:40

A dynamic vibration absorber is shown in Figure P2.2. This system is representative of many situations involving the vibration of machines containing unbalanced components. The parameters $M_2$ and $k_{12}$ may be chosen so that the main mass $M_1$ does not vibrate in the steady state when $F(t)=a \sin \left(\omega_0 t\right)$. Obtain the differential equations describing the system.
Figure can't copy

James Kiss

Numerade Educator

05:11

Problem 3

A coupled spring-mass system is shown in Figure P2.3. The masses and springs are assumed to be equal. Obtain the differential equations describing the system.
Figure can't copy

Samuel Hannah

Numerade Educator

Problem 4

P2.4 A nonlinear amplifier can be described by the following characteristic:
$$
v_0(t)=\left\{\begin{array}{rl}
v_{\text {in }}^2 & v_{\text {in }} \geq 0 \\
-v_{\text {in }}^2 & v_{\text {in }}<0
\end{array} .\right.
$$

The amplifier will be operated over a range of \pm 0.5 volts around the operating point for $v_{\text {in }}$. Describe the amplifier by a linear approximation (a) when the operating point is $v_{\text {in }}=0$ and (b) when the operating point is $v_{\text {in }}=1$ volt. Obtain a sketch of the nonlinear function and the approximation for each case.

Check back soon!

02:57

Problem 5

Fluid flowing through an orifice can be represented by the nonlinear equation
$$
Q=K\left(P_1-P_2\right)^{1 / 2},
$$
where the variables are shown in Figure P2.5 and $K$ is a constant [2]. (a) Determine a linear approximation for the fluid-flow equation. (b) What happens to the approximation obtained in part (a) if the operating point is $P_1-P_2=0$ ?
Figure can't copy

Amany Waheeb

Numerade Educator

Problem 6

Obtain the transfer function
for the two-mass system given in Figure P2.6.
Figure can't copy

Check back soon!

02:29

Problem 7

Obtain the transfer function of the differentiating circuit shown in Figure P2.7.
Figure can't copy

Arpit Gupta

Numerade Educator

03:13

Problem 8

A bridged-T network is often used in AC control systems as a filter network [8]. The circuit of one bridged-T network is shown in Figure P2.8. Show that the transfer function of the network is
$$
\frac{V_0(s)}{V_{\mathrm{in}}(s)}=\frac{1+2 R_1 C s+R_1 R_2 C^2 s^2}{1+\left(2 R_1+R_2\right) C s+R_1 R_2 C^2 s^2} .
$$

Sketch the pole-zero diagram when $R_1=0.5, R_2=1$, and $C=0.5$.

Narayan Hari

Numerade Educator

19:02

Problem 9

Determine the transfer function $X_1(s) / F(s)$ for the coupled spring-mass system of Problem 2.3. Sketch the $s$-plane pole-zero diagram for low damping when $M=1, b / k=1$, and
$$
\zeta=\frac{1}{2} \frac{b}{\sqrt{k M}}=0.1 .
$$

Ahmad Reda

Numerade Educator

01:52

Problem 10

Determine the transfer function $Y_1(s) / F(s)$ for the vibration absorber system of Problem 2.2. Determine the necessary parameters $M_2$ and $k_{12}$ so that the mass $M_1$ does not vibrate in the steady state when $F(t)=a \sin \left(\omega_0 t\right)$.

James Kiss

Numerade Educator

01:41

Problem 11

For electromechanical systems that require large power amplification, rotary amplifiers are often used $[8,19]$. An amplidyne is a power amplifying rotary amplifier. An amplidyne and a servomotor are shown in Figure P2.11. Obtain the transfer function $\theta(s) / V_c(s)$, and draw the block diagram of the system. Assume $v_{d d}=k_2 i_q$ and $v_q=k_1 i_c$.

Kajal Gautam

Numerade Educator

Problem 12

For the open-loop control system described by the block diagram shown in Figure P2.12, determine the value of $K$ such that $y(t) \rightarrow 10$ as $t \rightarrow \infty$ when $r(t)$ is a unit step input. Assume zero initial conditions.

Check back soon!

06:01

Problem 13

An electromechanical open-loop control system is shown in Figure P2.13. The generator, driven at a constant speed, provides the field voltage for the motor. The motor has an inertia $J_m$ and bearing friction $b_m$. Obtain the transfer function $\theta_L(s) / V_f(s)$ and draw a block diagram of the system. The generator voltage $v_R$ can be assumed to be proportional to the field current $i_f$.

Aatish Gupta

Numerade Educator

01:14

Problem 14

A rotating load is connected to a field-controlled DC electric motor through a gear system. The motor is assumed to be linear. A test results in the output load reaching a speed of $1 \mathrm{rad} / \mathrm{s}$ within $0.5 \mathrm{~s}$ when a constant $80 \mathrm{~V}$ is applied to the motor terminals. The output steady-state speed is $2.4 \mathrm{rad} / \mathrm{s}$. Determine the transfer function $\theta(s) / V_f(s)$ of the motor, in $\mathrm{rad} / \mathrm{V}$. The inductance of the field may be assumed to be negligible (see Figure 2.18). Also, note that the application of $80 \mathrm{~V}$ to the motor terminals is a step input of $80 \mathrm{~V}$ in magnitude.

Dominador Tan

Numerade Educator

03:59

Problem 15

Consider the spring-mass system depicted in Figure P2.15. Determine a differential equation to describe the motion of the mass $m$. Obtain the system response $x(t)$ with the initial conditions $x(0)=x_0$ and $\dot{x}(0)=0$.

Mike Gaerlan

Numerade Educator

01:12

Problem 16

Obtain a signal-flow graph to represent the following set of algebraic equations where $x_1$ and $x_2$ are to be considered the dependent variables and 6 and 11 are the inputs:
$$
x_1+1.5 x_2=6, \quad 2 x_1+4 x_2=11 .
$$

Determine the value of each dependent variable by using the gain formula. After solving for $x_1$ by Mason's signal-flow gain formula, verify the solution by using Cramer's rule.

Trinity Steen

Numerade Educator

04:06

Problem 17

A mechanical system is shown in Figure P2.17. which is subjected to a known displacement $x_3(t)$ with respect to the reference. (a) Determine the two independent equations of motion. (b) Obtain the equations of motion in terms of the Laplace transform, assuming that the initial conditions are zero. (c) Sketch a signalflow graph representing the system of equations. (d) Obtain the relationship $T_{13}(s)$ between $X_1(s)$ and $X_3(s)$ by using Mason's signal-flow gain formula. Compare the work necessary to obtain $T_{13}(s)$ by matrix methods to that using Mason's signal-flow gain formula.

James Kiss

Numerade Educator

05:20

Problem 18

An $L C$ ladder network is shown in Figure P2.18. One may write the equations describing the network as follows:
$$
\begin{array}{ll}
I_1=\left(V_1-V_a\right) Y_1, & V_a=\left(I_1-I_a\right) Z_2, \\
I_a=\left(V_a-V_2\right) Y_3, & V_2=I_a Z_4 .
\end{array}
$$

Construct a flow graph from the equations and determine the transfer function $V_2(s) / V_1(s)$.

Arpit Gupta

Numerade Educator

01:33

Problem 19

A voltage follower (buffer amplifier) is shown in Figure P2.19. Show that $T=v_0 / v_{\text {in }}=1$. Assume an ideal op-amp.

Khoobchandra Agrawal

Numerade Educator

Problem 20

The source follower amplifier provides lower output impedance and essentially unity gain. The circuit diagram is shown in Figure P2.20(a), and the small-signal model is shown in Figure P2.20(b). This circuit uses an FET and provides a gain of approximately unity. Assume that $R_2 \gg R_1$ for biasing purposes and that $R_g \gg R_2$. (a) Solve for the amplifier gain. (b) Solve for the gain when $g_n=2000 \mu \Omega$ and $R_s=10 \mathrm{k} \Omega$ where $R_5=R_1+R_2$. (c) Sketch a block diagram that represents the circuit equations.

Check back soon!

14:53

Problem 21

A hydraulic servomechanism with mechanical feedback is shown in Figure P2.21 [19]. The power piston has an area equal to $A$. When the valve is moved a small amount $\Delta z$, the oil will flow through to the cylinder at a rate $p \cdot \Delta z$, where $p$ is the port coefficient. The input oil pressure is assumed to be constant. From the geometry, we find that $\Delta z=k \frac{l_1-l_2}{l_1}(x-y)-\frac{l_2}{l_1} y$. (a) Determine the closed-loop signal-flow graph or block diagram for this mechanical system. (b) Obtain the closed-loop transfer function $Y(s) / X(s)$.

Mahnoor Amin

Numerade Educator

04:42

Problem 22

Figure P2.22 shows two pendulums suspended from frictionless pivots and connected at their midpoints by a spring [1].Assume that each pendulum can be represented by a mass $M$ at the end of a massless bar of length $L$. Also assume that the displacement is small and linear approximations can be used for $\sin \theta$ and $\cos \theta$. The spring located in the middle of the bars is unstretched when $\theta_1=\theta_2$. The input force is represented by $f(t)$, which influences the left-hand bar only. (a) Obtain the equations of motion, and sketch a block diagram for them. (b) Determine the transfer function $T(s)=\theta_1(s) / F(s)$. (c) Sketch the location of the poles and zeros of $T(s)$ on the $s$-plane.

Shoukat Ali

Other Schools

04:44

Problem 23

The small-signal circuit equivalent to a commonemitter transistor amplifier is shown in Figure P2.23. The transistor amplifier includes a feedback resistor $R_f$. Determine the input-output ratio $v_{c e} / v_{\text {in }}$.

William Mead

Numerade Educator

Problem 24

A two-transistor series voltage feedback amplifier is shown in Figure P2.24(a). This AC equivalent circuit neglects the bias resistors and the shunt capacitors. A block diagram representing the circuit is shown in Figure P2.24(b). This block diagram neglects the effect of $h_{r e}$, which is usually an accurate approximation, and assumes that $R_2+R_L \gg R_1$. (a) Determine the voltage gain $v_{\mathrm{o}} / v_{\mathrm{in}}$. (b) Determine the current gain $i_{c 2} / i_{b 1}$. (c) Determine the input impedance $v_{\text {in }} / i_{b 1}$.

Check back soon!

Problem 25

H. S. Black is noted for developing a negative feedback amplifier in 1927. Often overlooked is the fact that three years earlier he had invented a circuit design technique known as feedforward correction [20]. Recent experiments have shown that this technique offers the potential for yielding excellent amplifier stabilization. Black's amplifier is shown in Figure P2.25(a) in the form recorded in 1924. The block diagram is shown in Figure P2.25(b). Determine the transfer function between the output $Y(s)$ and the input $R(s)$ and between the output and the disturbance $T_d(s) . G(s)$ is used to denote the amplifier represented by $\mu$ in Figure P2.25(a).

Check back soon!

04:11

Problem 26

A robot includes significant flexibility in the arm members with a heavy load in the gripper $[6,21]$. A two-mass model of the robot is shown in Figure. P2.26. Find the transfer function $Y(s) / F(s)$.

Surjit Tewari

Numerade Educator

01:57

Problem 27

Magnetic levitation trains provide a high-speed, very low friction alternative to steel wheels on steel rails. The train floats on an air gap as shown in Figure P2.27 [27]. The levitation force $F_L$ is controlled by the coil current $i$ in the levitation coils and may be approximated by
$$
F_L=k \frac{i^2}{z^2},
$$
where $z$ is the air gap. This force is opposed by the downward force $F=m g$. Determine the linearized relationship between the air gap $z$ and the controlling current near the equilibrium condition.

Ankur S

Numerade Educator

Problem 28

A multiple-loop model of an urban ecological system might include the following variables: number of people in the city $(P)$, modernization $(M)$, migration into the city $(C)$, sanitation facilities $(S)$, number of diseases $(D)$, bacteria/area $(B)$, and amount of garbage/area $(G)$, where the symbol for the variable is given in parentheses. The following causal loops are hypothesized:
1. $P \rightarrow G \rightarrow B \rightarrow D \rightarrow P$
2. $P \rightarrow M \rightarrow C \rightarrow P$
3. $P \rightarrow M \rightarrow S \rightarrow D \rightarrow P$
4. $P \rightarrow M \rightarrow S \rightarrow B \rightarrow D \rightarrow P$
Sketch a signal-flow graph for these causal relationships, using appropriate gain symbols. Indicate whether you believe each gain transmission is positive or negative. For example, the causal link $S$ to $B$ is negative because improved sanitation facilities lead to reduced bacteria/area. Which of the four loops are positive feedback loops and which are negative feedback loops?

Check back soon!

05:13

Problem 29

We desire to balance a rolling ball on a tilting beam as shown in Figure P2.29. We will assume the motor input current $i$ controls the torque with negligible friction. Assume the beam may be balanced near the horizontal $(\phi=0)$; therefore, we have a small deviation of $\phi$. Find the transfer function $X(s) / I(s)$, and draw a block diagram illustrating the transfer function showing $\phi(s), X(s)$, and $I(s)$.

Eric Mockensturm

Numerade Educator

Problem 30

The measurement or sensor element in a feedback system is important to the accuracy of the system [6]. The dynamic response of the sensor is important. Most sensor elements possess a transfer function
$$
H(s)=\frac{k}{\tau s+1}
$$

Suppose that a position-sensing photo detector has $\tau=4 \mu$ s and $0.999<k<1.001$. Obtain the step response of the system, and find the $k$ resulting in the fastest response-that is, the fastest time to reach $98 \%$ of the final value.

Check back soon!

01:10

Problem 31

Consider the cable reel control system given in Figure $P 2.31$. Find the value of $K$ such that for a desired velocity of $50 \mathrm{~m} / \mathrm{s}$, the percent overshoot is less than $9 \%$.

Ahmed Kamel

Numerade Educator

Problem 32

Obtain the overall transfer function of the system given in Figure P2.32.

Check back soon!

03:10

Problem 33

A system consists of two electric motors that are coupled by a continuous flexible belt. The belt also passes over a swinging arm that is instrumented to allow measurement of the belt speed and tension. The basic control problem is to regulate the belt speed and tension by varying the motor torques.
An example of a practical system similar to that shown occurs in textile fiber manufacturing processes when yarn is wound from one spool to another at high speed. Between the two spools, the yarn is processed in a way that may require the yarn speed and tension to be controlled within defined limits. A model of the system is shown in Figure P2.33. Find $Y_2(s) / R_1(s)$. Determine a relationship for the system that will make $Y_2$ independent of $R_1$.

Mayukh Banik

Numerade Educator

01:43

Problem 34

Find the transfer function for $Y(s) / R(s)$ for the idlespeed control system for a fuel-injected engine as shown in Figure P2.34.

Amit Srivastava

Numerade Educator

03:30

Problem 35

The suspension system for one wheel of an oldfashioned pickup truck is illustrated in Figure P2.35. The mass of the vehicle is $m_1$ and the mass of the wheel is $m_2$. The suspension spring has a spring constant $k_1$ and the tire has a spring constant $k_2$. The damping constant of the shock absorber is $b$. Obtain the transfer function $Y_1(s) / X(s)$, which represents the vehicle response to bumps in the road.

Averell Hause

Carnegie Mellon University

Problem 36

A feedback control system has the structure shown in Figure P2.36. Determine the closed-loop transfer function $Y(s) / R(s)$ (a) by block diagram manipulation and (b) by using a signal-flow graph and Mason's signal-flow gain formula. (c) Select the gains $K_1$ and $K_2$ so that the closed-loop response to a step input is critically damped with two equal roots at $s=-10$. (d) Plot the critically damped response for a unit step input. What is the time required for the step response to reach $90 \%$ of its final value?

Check back soon!

Problem 37

Figure can't copy
(a) Obtain the overall transfer function $\frac{Y(s)}{R(s)}$ of the system given in Figure P2.37.
(b) Obtain the closed-loop poles, open-loop poles and expression for step response when $K=1$.
(c) Repeat (b) for $K=10$.

Check back soon!

05:20

Problem 38

(a) Draw the signal flow graph corresponding to the system shown in Figure P2.38.
(b) Find the overall transfer function
$$
\frac{V_4(s)}{V_1(s)}
$$
using Masons Gain Formula.

Arpit Gupta

Numerade Educator

04:55

Problem 39

A winding oscillator consists of two steel spheres on each end of a long slender rod, as shown in Figure P2.39. The rod is hung on a thin wire that can be twisted many revolutions without breaking. The device will be wound up 4000 degrees. How long will it take until the motion decays to a swing of only 10 degrees? Assume that the thin wire has a rotational spring constant of $2 \times 10^{-4} \mathrm{~N} \mathrm{~m} / \mathrm{rad}$ and that the viscous friction coefficient for the sphere in air is $2 \times 10^{-4} \mathrm{~N} \mathrm{~m} \mathrm{~s} / \mathrm{rad}$. The sphere has a mass of $1 \mathrm{~kg}$.

Chad Smith

Numerade Educator

Problem 40

For the circuit of Figure P2.40, determine the transform of the output voltage $V_0(s)$. Assume that the circuit is in steady state when $t<0$. Assume that the switch moves instantaneously from contact 1 to contact 2 at $t=0$.

Check back soon!

02:56

Problem 41

A damping device is used to reduce the undesired vibrations of machines. A viscous fluid, such as a heavy oil, is placed between the wheels, as shown in Figure P2.41. When vibration becomes excessive, the relative motion of the two wheels creates damping. When the device is rotating without vibration, there is no relative motion and no damping occurs. Find $\theta_1(s)$ and $\theta_2(s)$. Assume that the shaft has a spring constant $K$ and that $b$ is the damping constant of the fluid. The load torque is $T$.

Khoobchandra Agrawal

Numerade Educator

03:11

Problem 42

The lateral control of a rocket with a gimbaled engine is shown in Figure P2.42. The lateral deviation from the desired trajectory is $h$ and the forward rocket speed is $V$. The control torque of the engine is $T_c$ and the disturbance torque is $T_d$. Derive the describing equations of a linear model of the system, and draw the block diagram with the appropriate transfer functions.

Sriparna Bhattacharjee

Numerade Educator

01:44

Problem 43

In many applications, such as reading product codes in supermarkets and in printing and manufacturing, an optical scanner is utilized to read codes, as shown in Figure P2.43. As the mirror rotates, a friction force is developed that is proportional to its angular speed. The friction constant is equal to $0.06 \mathrm{~N} \mathrm{~s} / \mathrm{rad}$, and the moment of inertia is equal to $0.1 \mathrm{~kg} \mathrm{~m}^2$. The output variable is the velocity $\omega(t)$. (a) Obtain the differential equation for the motor. (b) Find the response of the system when the input motor torque is a unit step and the initial velocity at $t=0$ is equal to 0.7 .

Narayan Hari

Numerade Educator

03:32

Problem 44

An ideal set of gears is shown in Table 2.5, item 10. Neglect the inertia and friction of the gears and assume that the work done by one gear is equal to that of the other. Derive the relationships given in item 10 of Table 2.5. Also, determine the relationship between the torques $T_n$ and $T_L$.

Paul Gabriel

Numerade Educator

13:14

Problem 45

An ideal set of gears is connected to a solid cylinder load as shown in Figure P2.45. The inertia of the motor shaft and gear $G_2$ is $J_m$. Determine (a) the inertia of the load $J_L$ and (b) the torque $T$ at the motor shaft. Assume the friction at the load is $b_L$ and the friction at the motor shaft is $b_m$. Also assume the density of the load disk is $\rho$ and the gear ratio is $n$. Hint: The torque at the motorshaft is given by $T=T_1+T_m$.

Khoobchandra Agrawal

Numerade Educator

Problem 46

To exploit the strength advantage of robot manipulators and the intellectual advantage of humans, a class of manipulators called extenders has been examined [23]. The extender is defined as an active manipulator worn by a human to augment the human's strength. The human provides an input $U(s)$, as shown in Figure $\mathrm{P} 2.46$. The endpoint of the extender is $P(s)$. Determine the output $P(s)$ for both $U(s)$ and $F(s)$ in the form
$$
P(s)=T_1(s) U(s)+T_2(s) F(s) .
$$

Check back soon!

02:18

Problem 47

A load added to a truck results in a force $F$ on the support spring, and the tire flexes as shown in Figure P2.47(a). The model for the tire movement is shown in Figure $\mathrm{P} 2 \cdot 47(\mathrm{~b})$. Determine the transfer function $X_1(s) / F(s)$.

Averell Hause

Carnegie Mellon University

05:25

Problem 48

The water level $h(t)$ in a tank is controlled by an open-loop system, as shown in Figure P2.48. A DC motor controlled by an armature current $i_a$ turns a shaft, opening a valve. The inductance of the DC motor is negligible, that is, $L_a=0$. Also, the rotational friction of the motor shaft and valve is negligible, that is, $b=0$. The height of the water in the tank is
$$
h(t)=\int[1.6 \theta(t)-h(t)] d t,
$$
the motor constant is $K_m=10$, and the inertia of the motor shaft and valve is $J=6 \times 10^{-3} \mathrm{~kg} \mathrm{~m}^2$. Determine (a) the differential equation for $h(t)$ and $v(t)$ and (b) the transfer function $H(s) / V(s)$.

Hariprasad Annamalai

Numerade Educator

04:57

Problem 49

The circuit shown in Figure P2.49 is called a leadlag filter.
(a) Find the transfer function $V_2(s) / V_1(s)$. Assume an ideal op-amp.
(b) Determine $V_2(s) / V_1(s)$ when $R_1=100 \mathrm{k} \Omega$, $R_2=200 k \Omega, C_1=1 \mu F$, and $C_2=0.1 \mu F$.
(c) Determine the partial fraction expansion for $V_2(s) / V_1(s)$.

Kajal Gautam

Numerade Educator

Problem 50

A closed-loop control system is shown in Figure P2.50.
(a) Determine the transfer function
$$
T(s)=Y(s) / R(s) .
$$
(b) Determine the poles and zeros of $T(s)$.
(c) Use a unit step input, $R(s)=1 / s$, and obtain the partial fraction expansion for $Y(s)$ and the value of the residues.
(d) Plot $y(t)$ and discuss the effect of the real and complex poles of $T(s)$. Do the complex poles or the real poles dominate the response?

Check back soon!

04:25

Problem 51

Obtain the transfer function of the $R L C$ network shown in Figure P2.51. Given $L=1 \mathrm{H}, C=0.01 \mu \mathrm{F}$. Find the closed loop poles, damping ratio, natural frequency of oscillation when
(a) $R=10 \mathrm{k}$
(b) $R=2 \mathrm{k}$

Kajal Gautam
