A cell has an emf of 1.44 V and an internal resistance of...

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Voltage Drop

The voltage drop is the reduction in voltage as current flows through a resistive element, such as the internal resistance of a cell. It quantifies the amount by which the cell’s emf is reduced before the voltage is applied to an external circuit, determining the effective operating voltage of the system.

Ohm's Law

Ohm's Law is a fundamental principle stating that the voltage drop across a resistor is directly proportional to the current flowing through it and its resistance (V = IR). This relationship is critical for calculating how internal resistance decreases the voltage supplied to the external load.

Electromotive Force (emf)

The electromotive force (emf) represents the ideal voltage produced by a cell or battery when no current is flowing. It is driven by the chemical reactions within the cell and is the maximum potential difference available before any losses due to internal resistance are considered.

Internal Resistance

Internal resistance is an inherent property of a cell or battery that opposes the flow of current, resulting in a voltage drop when current flows. This resistance converts some of the battery’s energy into heat, reducing the effective voltage available to an external circuit.
