(a) Consider a Schottky diode at T=300 K that is formed with tungsten on n -type silicon. Use F

step 1 So in this question we have to determine the forward bias voltage required to induce the current

(a) Consider a Schottky diode at T=300 K that is formed...

(a) Consider a Schottky diode at $T=300 \mathrm{~K}$ that is formed with tungsten on $\mathrm{n}$ -type silicon. Use Figure $9.5$ to determine the barrier height. Assume a doping concentration of $N_{d}=10^{16} \mathrm{~cm}^{-3}$ and assume a cross-sectional area $A=10^{-4} \mathrm{~cm}^{2}$. Determine the forward-bias voltage required to induce a current of $(i) 10 \mu \mathrm{A},(i i) 100 \mu \mathrm{A}$, and (iii) $1 \mathrm{~mA}$. $(b)$ Repeat part $(a)$ for a temperature of $T=350 \mathrm{~K}$. (Neglect the barrier lowering effect.)

(a) Consider a Schottky diode at $T=300 \mathrm{~K}$ that is formed with tungsten on $\mathrm{n}$ -type silicon. Use Figure $9.5$ to determine the barrier height. Assume a doping concentration of $N_{d}=10^{16} \mathrm{~cm}^{-3}$ and assume a cross-sectional area $A=10^{-4} \mathrm{~cm}^{2}$. Determine the forward-bias voltage required to induce a current of $(i) 10 \mu \mathrm{A},(i i) 100 \mu \mathrm{A}$, and
(iii) $1 \mathrm{~mA}$. $(b)$ Repeat part $(a)$ for a temperature of $T=350 \mathrm{~K}$. (Neglect the barrier lowering effect.)

Key Concepts

Schottky Diode

A Schottky diode is a metal?semiconductor junction device that differs from a p–n junction diode due to its majority carrier operation. Its fast switching speeds and low forward voltage drop arise from the absence of minority carrier injection and the related storage effects, making it useful in power and high-frequency applications.

Barrier Height

The barrier height is the energy difference at the metal–semiconductor interface that electrons must overcome to contribute to current conduction. It fundamentally determines the diode’s turn-on characteristics and is influenced by the metal work function and the semiconductor’s electron affinity.

Thermionic Emission Theory

Thermionic emission theory explains charge carrier transport in Schottky diodes as carriers that acquire sufficient thermal energy to overcome the potential barrier at the metal–semiconductor interface. This theory forms the basis for modeling the current-voltage characteristics of the device, especially under forward bias conditions.

Forward Bias Voltage

In the operation of a semiconductor diode, the forward bias voltage is the external potential applied to reduce the effective energy barrier, facilitating the flow of charge carriers. In Schottky diodes, calculating the required forward bias to achieve specific current levels involves understanding the barrier lowering and the dependence on temperature.

Temperature Dependence

Temperature plays a critical role in Schottky diode performance as it influences thermionic emission. Higher temperatures increase the thermal energy available to carriers, thereby reducing the forward bias needed to achieve a given current, which is an important factor in device design and analysis.

Doping Concentration

Doping concentration in the semiconductor influences the width of the depletion region at the junction and the electric field profile. In an n-type semiconductor forming a Schottky diode, the level of doping affects the current conduction by modifying the carrier concentration near the interface.

Device Area

The cross-sectional area of the diode is important as it directly scales the total current from the current density. For a given barrier and current density derived from thermionic emission theory, the diode’s area determines the macroscopic current output, linking microscopic physics to device-level performance.
