Draw a crystal field energy-level diagram, assign the electrons to orbitals, and predict the num

Draw a crystal field energy-level diagram, assign the...

Key Concepts

d-Orbital Splitting in Octahedral Fields

In an octahedral field, the five d orbitals split into two sets: a lower-energy set (t2g) and a higher-energy set (eg). The magnitude of this splitting, often denoted as ??, is determined by the nature of the ligands and the metal ion. Understanding this splitting is crucial for predicting the distribution of electrons, the magnetic properties, and the overall stability of the complex.

Jahn-Teller Distortion

Jahn-Teller Distortion is a phenomenon observed in certain transition metal complexes where an asymmetrical distribution of electrons in degenerate orbitals leads to a distortion of the complex geometry. This effect is particularly common in complexes with an uneven number of electrons in the eg set, such as d^9 systems, and results in a lowering of the overall energy by breaking the degeneracy of the orbitals, often affecting the predicted magnetic and spectral properties of the complex.

High-Spin vs Low-Spin Complexes

The distinction between high-spin and low-spin complexes arises from the competition between the crystal field splitting energy (??) and the electron pairing energy. When ?? is small relative to the pairing energy, electrons occupy higher energy orbitals to remain unpaired, resulting in high-spin configurations. Conversely, when ?? is large, electrons pair up in the lower energy orbitals to minimize energy, leading to low-spin configurations. The nature of the ligands, whether they are strong-field or weak-field, plays a fundamental role in this behavior.

Crystal Field Theory

Crystal Field Theory is a model that describes the electronic structure of transition metal complexes by considering the effect of the electric field produced by surrounding ligands on the d orbitals of the metal ion. This theory explains how the degeneracy of the d orbitals is lifted when ligands approach and interact with the metal, leading to different energy levels in various geometries, most commonly octahedral, tetrahedral, or square planar environments.

Electron Configuration in Transition Metal Complexes

Electron configuration in transition metal complexes involves assigning the appropriate number of d electrons, based on the oxidation state of the metal, to the split d orbitals following the rules of quantum mechanics. The electrons are filled into the available orbitals by considering considerations like the Pauli Exclusion Principle and Hund’s Rule, which help determine the number of unpaired electrons and the overall spin state of the complex.

Transcript

00:01 So in this question we draw crystal field energy level diagram of the following complexes and then find out the number of unped electron in these complexes.

00:09 So our first complex is copper complex that is copper ethylene diamine complex.

00:15 So here en is the ethylene.

00:18 So here en is the ethylene diamine, which is a bidentate ligand and if we draw a structure of this, so it looks like this.

00:30 H2 it looks like this so see it like this nh2 and this so here we see that this is a structure of ethylene diamond here we see that there is the two donor atom it is a bi -dentate ligand as i already said bidentate ligand so that means for each italym two donor atom present and for three it means six donor atom are present so that means it form an octahedral complex so before draw the crystal field we write the electronic configuration so here copper atom copper is the matter that is involved in this complex so copper is 29 so we can write here argon and 3d9 4 s2 so here copper 2 because here ethylene diamine is a neutral ligand so that's why so here argan which is 18 and 3d9 that means 2 electron are removed from as orbital now we draw the crystal field energy level diagram so this is our d orbital so like these and this is our energy so this is the energy now see this ethylene diamine so it is a strong ligand so it undergo low spin complexes and there is a pairing can take place so we paired these nine electron in this case so we paired like one two three four five six seven eight and nine and we will see that here like this only one unpaid electron so one unpaired electron is present in this complex.

02:07 Now part b of the question is iron complex that is iron f .ef6 and 3 negative.

02:15 So first write the electronic configuration of iron.

02:19 That means 26 which come out to be argon 18 and this 3d6 and 4s2...
