If a solid shaft having a diameter $d$ is subjected to a torque $\mathbf{T}$ and moment $\mathbf{M}$, show that by the maximumshear-stress theory the maximum allowable shear stress is $\tau_{\text {allow }}=\left(16 / \pi d^{3}\right) \sqrt{M^{2}+T^{2}} .$ Assume the principal stresses to be of opposite algebraic signs.

Key Concepts

Principal Stresses

The concept of principal stresses involves transforming the complex state of stress at a point so that the shear components are eliminated and only normal stresses remain. Assuming the principal stresses have opposite signs is a common situation in bending of shafts, and it allows for the accurate application of failure theories like the maximum shear stress theory, by finding the extreme values necessary for safe design.

Stress Distribution in Circular Shafts

For a solid circular shaft, the distribution of stresses due to bending and torsion can be derived based on geometry and material behavior. Bending induces a linear stress distribution across the cross-section while torsion requires knowledge of the polar moment of inertia to determine the shear stress. The superposition of these stress fields allows for the derivation of an equivalent stress measure in the context of failure theories.

Maximum Shear Stress Theory

This theory, also known as the Tresca criterion, is a failure criterion used in solid mechanics that states that yielding begins when the maximum shear stress in a material reaches a critical value. It is particularly useful when evaluating components under complex loading since it simplifies the analysis by focusing on the maximum shear stresses rather than the complete stress state.

Combined Loading Effects

In many engineering components, loads are not applied in isolation but rather as a combination of different types such as bending moments and torsional moments. Understanding how these combined effects influence the stress state is critical, as the different loading modes interact to produce a resultant stress field that must be assessed to ensure the component’s integrity.
