Multiple-Concept Example 10 reviews the approach and some of the concepts that are pertinent to this problem. The drawing shows a model for the motion of the human forearm in throwing a dart. Because of the force $\overrightarrow{\mathbf{M}}$ applied by the triceps muscle, the forearm can rotate about an axis at the elbow joint. Assume that the forearm has the dimensions shown in the drawing and a moment of inertia of $0.065 \mathrm{kg} \cdot \mathrm{m}^{2}$ (including the effect of the dart) relative to the axis at the elbow. Assume also that the force $\overrightarrow{\mathbf{M}}$ acts perpendicular to the forearm. Ignoring the effect of gravity and any frictional forces, determine the magnitude of the force $\overrightarrow{\mathbf{M}}$ needed to give the dart a tangential speed of $5.0 \mathrm{m} / \mathrm{s}$ in $0.10 \mathrm{s},$ starting from rest.

Key Concepts

Angular Kinematics

Angular kinematics deals with the motion of rotating bodies, describing angular displacement, angular velocity, and angular acceleration over time. Understanding these concepts allows one to calculate the necessary acceleration to achieve a desired rotational speed over a given time.

Rotational Dynamics

This concept involves the study of objects in rotation and is governed by Newton's second law for rotation, which relates the net torque acting on an object to its moment of inertia multiplied by its angular acceleration. It forms the basis for analyzing how forces cause rotational motion.

Moment of Inertia

This is a measure of an object's resistance to changes in its rotational motion about a particular axis. It depends on the mass distribution relative to the axis of rotation and is crucial when determining the angular acceleration produced by a given torque.

Torque

Torque is the rotational equivalent of force. It is defined as the product of the applied force and the distance from the axis of rotation (the moment arm) at which the force is applied perpendicularly. It is the quantity that causes an object to undergo angular acceleration.

Relationship Between Angular and Tangential Quantities

This concept links the angular measures of rotation (such as angular velocity and angular acceleration) with the corresponding linear (tangential) quantities through the radius of rotation. For instance, the tangential speed of a point on a rotating body is the product of the angular speed and the distance from the rotation axis.
