The following picture shows the ethidium bromidestained bands revealed by gel electrophoresis of two different DNA samples digested with two different restriction enzymes. One of the DNAs is human genomic DNA, the other is the small genome of a bacteriophage (bacterial virus) that infects $E$. coli cells. One of the restriction enzymes is $E c o \mathrm{RI}\left(5^{\prime} \mathrm{G}^{\wedge} \mathrm{A} \mathrm{ATTC} 3^{\prime}\right) ;$ the other is HpaII$\left(5^{\prime} \mathrm{C}^{\wedge} \mathrm{CGG} 3^{\prime}\right) .$ For each of the four lanes on the gel (A-D), identify which of the two DNA samples was analyzed and which of the two restriction enzymes was used to digest that DNA. The arrow represents the direction of electrophoresis.

The following picture shows the ethidium bromidestained bands revealed by gel electrophoresis of two different DNA samples digested with two different restriction enzymes. One of the DNAs is human genomic DNA, the other is the small genome of a bacteriophage (bacterial virus) that infects $E$. coli cells. One of the restriction enzymes is $E c o \mathrm{RI}\left(5^{\prime} \mathrm{G}^{\wedge} \mathrm{A} \mathrm{ATTC} 3^{\prime}\right) ;$ the
other is HpaII$\left(5^{\prime} \mathrm{C}^{\wedge} \mathrm{CGG} 3^{\prime}\right) .$ For each of the four
lanes on the gel (A-D), identify which of the two DNA samples was analyzed and which of the two restriction enzymes was used to digest that DNA. The arrow represents the direction of electrophoresis.

Key Concepts

Genome Complexity and Fragmentation Patterns

Understanding genome complexity and fragmentation patterns is essential when analyzing different types of DNA. Genomes of higher organisms such as humans are larger and more complex, often yielding many fragments upon digestion, whereas smaller genomes, like those of bacteriophages, produce fewer and more discrete fragments. This difference is critical when interpreting gel electrophoresis results, as the pattern of bands reflects both the size of the genome and the frequency of the restriction sites within it.

Restriction Endonucleases

Restriction endonucleases, also known as restriction enzymes, are proteins that cut DNA at specific sequences called recognition sites. This controlled cleavage of DNA is fundamental in molecular biology for mapping genomes, cloning, and various forms of DNA analysis, as it produces fragments of predictable sizes based on the enzyme’s cutting pattern.

Ethidium Bromide Staining

Ethidium bromide staining is a method employed to visualize DNA bands after electrophoresis. The dye intercalates between DNA bases and fluoresces under ultraviolet light, making it possible to identify and compare the sizes and quantities of DNA fragments present in each lane.

Gel Electrophoresis

Gel electrophoresis is a laboratory technique used to separate DNA fragments according to their size by applying an electric field to a gel matrix. This method allows researchers to visualize and analyze the result of DNA digestion, with smaller fragments migrating faster and farther than larger ones, thereby revealing patterns that can be compared among different samples.
