A factory building is to be constructed over a rectangular area 22m x 36m and a car shed of area (6m x 36m). The main system is made up of steel trusses. Steel columns are provided along solid lines only, with a clear height of 6.00m. The covering material used is galvanized steel sheets.
It is required to draw a complete general layout to scale 1:100 or 1:200, showing all structural components including main trusses, purlins, and all bracing systems.
