(a) A Schottky barrier diode formed on n-type silicon has a doping concentration of $N_{d}=5 \times 10^{15} \mathrm{~cm}^{-3}$ and a barrier height of $\phi_{B 0}=0.65 \mathrm{~V}$. Determine the builtin potential barrier $V_{b i}$. $(b)$ If the doping concentration changes to $N_{d}=10^{16} \mathrm{~cm}^{-3}$, determine the values of $\phi_{B 0}$ and $V_{b i} .$ Do these values increase, decrease, or remain the same? (c) Repeat part ( $b$ ) if the doping concentration is $N_{d}=10^{15} \mathrm{~cm}^{-3}$.

(a) A Schottky barrier diode formed on n-type silicon has a doping concentration of $N_{d}=5 \times 10^{15} \mathrm{~cm}^{-3}$ and a barrier height of $\phi_{B 0}=0.65 \mathrm{~V}$. Determine the builtin potential barrier $V_{b i}$. $(b)$ If the doping concentration changes to $N_{d}=10^{16} \mathrm{~cm}^{-3}$, determine the values of $\phi_{B 0}$ and $V_{b i} .$ Do these values increase, decrease, or remain the same?
(c) Repeat part ( $b$ ) if the doping concentration is $N_{d}=10^{15} \mathrm{~cm}^{-3}$.

Key Concepts

Schottky Barrier Diode

A Schottky barrier diode is a semiconductor device formed by the junction of a metal with a semiconductor, characterized by a unidirectional current flow and low forward voltage drop. Its operation is governed by thermionic emission over the potential barrier created at the metal-semiconductor interface, which makes it useful in high-speed switching and microwave applications.

Schottky Barrier Height

The Schottky barrier height is the energy difference at the metal-semiconductor junction, representing the potential energy barrier that carriers must overcome to move from the semiconductor into the metal. This parameter is crucial as it directly influences the current-voltage characteristics of the device and determines its turn-on voltage and leakage current behavior.

Built-in Potential (V_bi)

The built-in potential, V_bi, is the internal voltage that develops across the depletion region of a diode in thermal equilibrium. It results from the difference in work functions between the metal and the semiconductor and from the doping concentration in the semiconductor, playing a key role in establishing the barrier for carrier flow at zero external bias.

Doping Concentration in Semiconductors

Doping concentration refers to the number of impurities added to a semiconductor to modify its electrical properties. In the context of Schottky diodes, the level of doping affects the width of the depletion region and the built-in potential, thereby influencing the diode's electrical behavior, such as its forward conduction and reverse leakage current.
