(a) Draw a flowchart for the catalytic dehydrogenation of propane from the description of this process that begins Section 4.3a. Label all feed, product, and connecting streams between units. (b) Write clear statements of the overall objective of the process and the functions of each of the process units (the preheater, the reactor, the absorption and stripping towers, and the distillation column).

(a) Draw a flowchart for the catalytic dehydrogenation of propane from the description of this process that begins Section 4.3a. Label all feed, product, and connecting streams between units.
(b) Write clear statements of the overall objective of the process and the functions of each of the process units (the preheater, the reactor, the absorption and stripping towers, and the distillation column).

Key Concepts

Absorption Tower

The absorption tower is used to selectively remove certain components from the reaction mixture. It typically involves contacting a gas or vapor stream with a liquid solvent, enabling the absorption of specific components based on their solubility characteristics, which aids in the purification or recovery of the desired product.

Distillation Column

The distillation column is a separation unit that separates components based on differences in their boiling points. Through repeated vaporization and condensation stages, the distillation column effectively segregates and purifies the reaction products, ensuring the final products meet the required purity specifications.

Stripping Tower

The stripping tower is employed to remove volatile compounds from a liquid stream by using a counter-current gas. This process helps in recovering valuable products or in purifying a stream by stripping out unwanted components, operating as a complementary process to absorption.

Reactor

The reactor is the central unit where the catalytic dehydrogenation occurs. Within this unit, the reactants are exposed to the catalyst under controlled temperature and pressure conditions to facilitate the dehydrogenation reaction, leading to the formation of the desired unsaturated product.

Overall Process Objective

The overall objective in a catalytic dehydrogenation process is to achieve effective conversion of reactants into desired unsaturated products, ensuring high selectivity and yield. This objective drives the design and operation of various process units structured to manage heat exchange, reaction kinetics, separation, and purification of products.

Process Flow Diagram

A process flow diagram (PFD) is a schematic representation of a chemical process that outlines the relationships between major process units. It clearly depicts the input and output streams, feedstocks, product streams, and intermediate process steps, facilitating analysis, design, and troubleshooting in process engineering.

Catalytic Dehydrogenation

This is a chemical process used to remove hydrogen from hydrocarbons by using a catalyst. The catalyst lowers the activation energy required for dehydrogenation, enhancing the selectivity and efficiency of converting saturated hydrocarbons into unsaturated products. This process is crucial in producing intermediate chemicals, which can be feedstocks for further chemical synthesis.

Preheater

The preheater is a unit designed to heat the reactant feed to an appropriate temperature prior to entering the reactor. This step is critical for optimizing the reaction kinetics and energy efficiency of the process by ensuring that the feed reaches the desired temperature for catalytic activity.
