A separately excited de motor (see the equivalent circuit shown in Figure 16.21 on page 788 ) has $R_{A}=1.3 \Omega$ and $V_{T}=220 \mathrm{V}$ For an output power of 3 hp $, n_{m}=950 \mathrm{rpm}$ and $I_{A}=12.2 \mathrm{A}$. The field current remains constant for all parts of this problem. a. Find the developed power, developed torque, power lost in $R_{A}$, and the rotational losses b. Assuming that the rotational power loss is proportional to speed, find the no-load speed of the motor

A separately excited de motor (see the equivalent circuit shown in Figure 16.21 on page 788 ) has $R_{A}=1.3 \Omega$ and $V_{T}=220 \mathrm{V}$ For an output power of 3 hp $, n_{m}=950 \mathrm{rpm}$ and $I_{A}=12.2 \mathrm{A}$. The field current remains constant for all parts of this problem. a. Find the developed power, developed torque, power lost in $R_{A}$, and the rotational losses
b. Assuming that the rotational power loss is proportional to speed, find the no-load speed of the motor

Key Concepts

DC Motor Equivalent Circuit

This concept represents the simplified electrical model of a DC motor that includes components such as the applied terminal voltage, armature resistance, and the generated back electromotive force (EMF). It helps in analyzing how the motor converts electrical input into mechanical output by accounting for voltage drops and losses in the circuit, thereby allowing operations like torque and speed calculation.

Armature Resistance Loss

This refers to the power dissipation occurring in the armature winding due to its inherent electrical resistance. It is calculated using the formula I²R, where I is the armature current and R is the resistance. This loss affects the efficiency of the motor and is a key factor in determining the net power available for mechanical work.

Developed Power in DC Motor

Developed power is the mechanical power generated by the motor prior to subtracting the mechanical losses. It is the difference between the input electrical power and the electrical losses (like the armature resistance losses), serving as the actual power available for conversion into mechanical work. This parameter is critical for sizing and performance analysis of DC motors.

Developed Torque in DC Motor

Developed torque is the torque produced by a motor based on the electromagnetic energy conversion taking place in the machine. It can be determined from the developed power and the operating speed, providing a measure of the motor’s ability to do mechanical work. This parameter is particularly important in applications where load dynamics and acceleration characteristics are crucial.

Rotational Losses in DC Motors

Rotational losses, also known as mechanical losses, include friction, windage, and other losses that occur during the conversion of electrical energy into mechanical energy. These losses are sometimes considered to be proportional to speed, meaning that as the motor’s speed increases, the amount of power lost to these sources tends to increase, affecting the overall efficiency of the motor.

No-Load Speed Determination

No-load speed refers to the speed of the motor when it is running without any load, thereby experiencing minimal output torque and only inherent rotational losses. Determining the no-load speed is important for understanding the motor’s performance characteristics, particularly since it is used as a reference point to assess how the motor behaves under various load conditions, especially when the loss mechanisms are speed-dependent.
