Question
A transistor with $\beta=50$ is placed in a common base amplifier circuit with $I_E=1 \mathrm{~mA}$ and $R_{\text {Leq }}=5 \mathrm{k} \Omega$. (a) What is the small-signal voltage gain? (b) Does this circuit invert the signal?
Step 1
We have: - Current gain, \(\beta = 50\) - Emitter current, \(I_E = 1 \, \text{mA} = 0.001 \, \text{A}\) - Equivalent load resistance, \(R_{\text{Leq}} = 5 \, \text{k}\Omega = 5000 \, \Omega\) Show more…
Show all steps
Your feedback will help us improve your experience
Brian Francisco and 50 other educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
A transistor, whose current gain $\beta=i_{\mathrm{C}} / i_{\mathrm{B}}=75,$ is connected as in Fig. $40-43$ with $R_{\mathrm{B}}=3.8 \mathrm{k} \Omega$ and $R_{\mathrm{C}}=7.8 \mathrm{k} \Omega .$ Calculate $(a)$ the voltage gain, and $(b)$ the power amplification.
(II) A transistor, whose current gain $\beta = i_C/i_B = 65$, is connected as in Fig. 29-41 with $R_B = 3.8 \mathrm{k}\Omega$ and $R_C = 7.8 \mathrm{k}\Omega$ Calculate ($a$) the voltage gain, and ($b$) the power amplification.
MOLECULES AND SOLIDS
Transistors: Bipolar and MOSFETs
The input resistance of a $C E$ amplifier is $333 \Omega$ and the load resistance is $5 \mathrm{k} \Omega$. A change of base current by $15 \mu$ A results in the change of collector current by 1 $\mathrm{mA}$. The voltage gain of the amplifier is (A) 550 (B) 101 (C) 1001 (D) 501
