At one instant, point P is 6.60 μm to the left of a proton that is moving at 3.30 km / s in vac

step 1 Okay, in this question, we're talking about magnetic field created by a moving charge. So in thi

At one instant, point P is 6.60 μm to the left of a proton...

At one instant, point $P$ is $6.60 \mu \mathrm{m}$ to the left of a proton that is moving at $3.30 \mathrm{~km} / \mathrm{s}$ in vacuum. (a) What is the direction of the unit vector in Eq. (28.2)$?$ (b) What is the magnetic field caused by this proton if it is moving to the right or to the left? (c) What is the magnetic field (magnitude and direction) caused by this proton if it is moving toward the top of the page? (d) What is the answer to part (c) for an electron instead of a proton?

Key Concepts

Unit Vector

A unit vector is a vector of length one that indicates direction only. In electromagnetic problems, it is used to specify the direction of forces or fields without affecting their magnitude. When determining the orientation of a field or force vector, the unit vector helps project the correct direction in space.

Right-Hand Rule

The right?hand rule is a common mnemonic in electromagnetism used to determine the direction of the magnetic field produced by a moving charged particle. It involves orienting the thumb in the direction of the charge’s velocity, with the fingers curling in the direction in which the magnetic field circulates; this rule is fundamental to predicting field directions in various coordinate systems.

Magnetic Field of a Moving Charge

This concept involves understanding that a moving charge produces a magnetic field, which can be computed using formulae derived from the Biot-Savart law. The field’s magnitude is proportional to the charge, the particle's speed, and inversely proportional to the distance from the particle, while its direction is given by the cross product of the velocity and the displacement vector from the charge to the point of interest.

Biot-Savart Law

The Biot-Savart law provides the fundamental relation for calculating the magnetic field generated by a current element or a moving charge. It expresses the magnetic field as proportional to the cross product of the current element (or velocity of the moving charge) and the unit vector pointing from the source to the field point, divided by the square (or cube) of the distance between them, thereby encapsulating both the magnitude and directional attributes of the field.

Effect of Charge Sign on Magnetic Field Direction

When calculating the magnetic field produced by a moving charge, the sign of the charge is critical as it determines the orientation of the magnetic field through the cross product in the governing equations. A positive charge will generate a field in one direction as predicted by the right-hand rule, while a negative charge produces a field in the opposite direction, leading to different field behaviors even if the magnitude of their velocities are identical.
